Specifications
|
DESCRIPTION |
UNIT |
VALUE |
VALUE |
VALUE |
VALUE |
VALUE |
VALUE |
VALUE |
|
|
1 |
GENERAL |
|
1X70mm2 8.7 / 15 (17.5) kV |
1x120mm2, 8.7 / 15 (17.5) kV |
1×150 mm2, 8.7 / 15 (17.5) kV |
1x70mm2, 18/30 (36) kV |
1X120mm2 FOR 18/30 (36) kV |
1×185 mm2, 8.7 / 15 (17.5) kV |
1X185mm2 FOR 18/30 (36) kV |
|
|
Standard |
|
NTP IEC 60502-2 |
NTP IEC 60502-2 |
NTP IEC 60502-2 |
NTP IEC 60502-2 |
NTP IEC 60502-2 |
NTP IEC 60502-2 |
NTP IEC 60502-2 |
|
2 |
DESIGNATION N2XSY |
1 x 70 mm2 |
1 x 120 mm2 |
1 x 150 mm2 |
1 x 70 mm2 |
1 x 120 mm2 |
1 x 185 mm2 |
1 x 185 mm2 |
|
|
|
Rated Voltage Uo / U (Uo) |
kV |
8.7 / 15 (17.5) |
8.7 / 15 (17.5) |
8.7 / 15 (17.5) |
18/30 (36) |
18/30 (36) |
8.7 / 15 (17.5) |
18/30 (36) |
|
|
Maximum temperature under normal conditions |
° C |
90 |
90 |
90 |
90 |
90 |
90 |
90 |
|
|
Maximum short-circuit temperature (5 s. Maximum) |
° C |
250 |
250 |
250 |
250 |
250 |
250 |
250 |
|
3 |
PHASE CONDUCTOR | ||||||||
|
|
Standard |
NTP IEC 60228 |
NTP IEC 60228 |
NTP IEC 60228 |
NTP IEC 60228 |
NTP IEC 60228 |
NTP IEC 60228 |
NTP IEC 60228 |
|
|
|
Material |
Uncoated Annealed Copper |
Uncoated Annealed Copper |
Uncoated Annealed Copper |
Uncoated Annealed Copper |
Uncoated Annealed Copper |
Uncoated Annealed Copper |
Uncoated Annealed Copper |
|
|
|
Purity |
% |
99.9 |
99.9 |
99.9 |
99.9 |
99.9 |
99.9 |
99.9 |
|
|
Nominal section |
mm2 |
70 |
120 |
150 |
70 |
120 |
185 |
185 |
|
|
Class |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
|
|
|
Minimum number of wires |
No. |
19 |
37 |
37 |
19 |
37 |
37 |
37 |
|
|
Density at 20 ° C |
gr / cm3 |
8.89 |
8.89 |
8.89 |
8.89 |
8.89 |
8.89 |
8.89 |
|
|
Electrical resistivity at 20 ° C |
Wmm2 / m |
0.017241 |
0.017241 |
0.017241 |
0.017241 |
0.017241 |
0.017241 |
0.017241 |
|
|
Maximum electrical resistance in DC at 20 ° C |
Ohm / km |
0.268 |
0.153 |
0.124 |
0.268 |
0.153 |
0.099 |
0.099 |
|
|
Insulation | ||||||||
| Material |
XLPE-TR (Tree Retardant Cross-linked Polyethylene) |
XLPE-TR (Tree Retardant Cross-linked Polyethylene) |
XLPE-TR (Tree Retardant Cross-linked Polyethylene) |
XLPE-TR (Tree Retardant Cross-linked Polyethylene) |
XLPE-TR (Tree Retardant Cross-linked Polyethylene) |
XLPE-TR (Tree Retardant Cross-linked Polyethylene) |
XLPE-TR (Tree Retardant Cross-linked Polyethylene) |
||
| Colour |
natural |
natural |
natural |
natural |
natural |
natural |
natural |
||
| Average nominal thickness |
mm |
4.5 |
4.5 |
4.5 |
8 |
8 |
4.5 |
8 |
|
|
|
Screen |
|
|
|
|
|
|
|
|
| Semiconductor tape or extruded compound semiconductor on the conductor |
YES |
YES |
YES |
YES |
YES |
YES |
YES |
||
| About the insulator | |||||||||
| Semiconductor tape or extruded composite semiconductor |
YES |
YES |
YES |
YES |
YES |
YES |
YES |
||
|
|
Copper wire braided mesh or tape with resistance less than 3 ohm/km at 20 ° C |
|
YES |
YES |
YES |
YES |
YES |
YES |
YES |
| Sheath | |||||||||
| Material |
PVC –ST2 |
PVC – ST2 |
PVC – ST2 |
PVC –ST2 |
PVC – ST2 |
PVC – ST2 |
PVC – ST2 |
||
| Colour |
Red |
Red |
Red |
Red |
Red |
Red |
Red |
||
| Minimal thickness |
mm |
1.2 |
1.2 |
1.3 |
1.4 |
1.5 |
1.4 |
1.6 |
|
|
|
Tests |
|
|
|
|
|
|
|
|
| Insulation Continuity Test Voltage |
kV |
30.5 |
30.5 |
30.5 |
63 |
63 |
30.5 |
63 |
|
| Insulation construction process |
Through simultaneous triple extrusion process |
Through simultaneous triple extrusion process |
Through simultaneous triple extrusion process |
Through simultaneous triple extrusion process |
Through simultaneous triple extrusion process |
Through simultaneous triple extrusion process |
Through simultaneous triple extrusion process |
