DIN Rail Single Phase Split Prepayment Energy Meter with Bottom Wiring
Type:
DDSY283SR-SP46Overview:
DDSY283SR-SP46 is a new generation of advanced single-phase two-wire, multi-function, split-type, dual-circuit metering prepaid energy meter. It fully complies with the STS standard. It can complete the prepayment business process and reduce the power company’s bad debt losses. The meter has high accuracy, low power consumption, and a CIU display unit, which is convenient for users to operate. The power company can choose different communication media to communicate with the data concentrator or CIU according to the requirements of them, such as PLC, RF and M-Bus. It is suitable for residential and commercial users. -
Single Phase Electricity Smart Meter
Type:
DDSD285-S16Overview:
DDSD285-S16 single phase electricity smart meter is designed for smart grids. It can not only accurately measure power consumption information, but also detect power quality parameters in real time. Holley smart meter integrates flexible communication technology supports interconnection in different communication environments. It supports remote data upload and remote relay switch off and on. It can reduce Power Company operating costs and realize demand side management; it also can realize remote firmware upgrade and rate distribution, which is convenient for power company operation and maintenance. The meter is an ideal residential and commercial product. -
ANSI Standards Socket Base Electricity Meter
Type:
DDSD285-S56 / DSSD536-S56Overview:
DDSD285-S56 / DSSD536-S56 are the high-performance and high-precision electronic energy meter designed in accordance with ANSI standards. It is suitable for Socket Base home, outdoor/indoor commercial use. Its accuracy is better than the 0.5 level specified by ANSI C12.20, and the wide working voltage is AC120V~480V.It supports ANSI type 2 optical communication interface, and includes AMI expansion interface. It is a high-end ANSI electronic energy meter for smart grid. The meter supports multi-channel metering channels and multi-channel demand can be set, it supports TOU, instantaneous value, load profile, event detection, connection and disconnection function. -
Three Phase Smart Prepayment Card Meter
Type:
DTSY541-SP36Overview:
DTSY541-SP36 three phase smart prepayment card meter is a new generation of smart energy meters, with stable performance, rich functions, strong anti-interference ability, and careful design in terms of convenient operation and data security. It adopts a fully sealed structure and shell, which can meet the severe high and low temperature alternating humidity and heat environment. The meter supports multiple communication methods to connect to the concentrator, such as PLC/RF or directly using GPRS. At the same time, the meter can also be used with CIU. It is an ideal product for commercial, industrial and residential use. -
Dry-type 3-20kv Current Transformer
Overview This type of current transformer is a dry-type, high-precision, dirt-proof indoors (outdoors) current transformer wrapped of epoxy resin. It is mainly used for measuring current, power, electric energy and relay protection in power system where the rated frequency of 50Hz and rated voltage of 10kV or 20kV and below. The specific operating conditions are follows: 1.The altitude does not exceed 1000 meters (when the altitude is over 1000m,The external insulation should be altitude corr... -
3-20KV Indoors / Outdoors Potential Transformer
Overview This type of potential transformer is an indoors (outdoors) product make of single phase epoxy resin insulation. It is mainly used for electric energy measurement, voltage measurement, monitor and relay protection in power system with the situation that neutral point not effectively grounded where the rated frequency is 50Hz and the rated voltage is 10kV or 20kV and below. -
10KV Full Enclosed Combination Transformer
Overview This type of combined transformer is a fully enclosed indoors (outdoors) product vacuum casted of epoxy resin. It has the good properties contains high insulation grade, anti-pollution ability, anti-ultraviolet and good hydrophobicity. The secondary outlet port is equipped with anti-tamper protective cover with rainproof, dustproof and corrosion resistant. The umbrella-proof skirt design is adopted in appearance, with long creepage distance on the surface. It is mainly used for elect... -
35kv Power System Combination Transformer
Overview The combined transformer is used for voltage and current energy measurement in 35kV power system in the situation of indoors and outdoors. The two current transformers are connected in series on the A and C phases of the line respectively. The two potential transformers constitute three phase V-type connection. This product is the composite insulation product make of epoxy resin and silicone rubber with stable performance. The external part use high temperature silicone rubber materi... -
35kv or Below Power System Current Transformer
Overview This type of current transformer is a dry-type, high-precision, dirt-proof, indoors use current transformer wrapped with epoxy resin. It is mainly used for measuring current, power, electric energy and relay protection in power systems with rated frequency of 50Hz and rated voltage of 35kV or below. The specific operating conditions are follows: 1. The altitude does not exceed 1000 meters (when the altitude is over 1000m, the external insulation should be altitude corrected and compr... -
35KV or Below Indoors / Outdoors Potential Transformer
Overview This type of potential transformer is an indoors (outdoors) product make of single phase epoxy resin insulation. It is mainly used for electric energy measurement, voltage measurement, monitor and relay protection with rated frequency of 50Hz and rated voltage of 35kV or below.in power system that the neutral point is not effectively grounded. -
Low Voltage Transformer
Overview This series transformer is made of thermosetting resin material. It has good electrical properties, mechanical properties and flame retardant properties with smooth surface, uniform color. Suitable for current and energy measurement and (or) relay protection in power lines with the situation that rated frequency 50Hz and rated voltage under and including 0.66kV. In order to make installation easily, the product has two kinds of structure: direct type and bus bar type. -
Zero Sequence Transformer
Overview This series of transformer is made of thermosetting resin material, which has good electrical properties, mechanical properties and flame retardant properties. It is used with relay protection devices or signals when the power system produces zero sequence grounding current. It enables the device components to make movement and realize the protection or monitoring.
